型號
Type |
外形尺寸
Overall dimensions
(mm) |
內膽尺寸
Drum Dimensions
(mm) |
電機功率
Moto power
(kw) |
風機功率
Moto power of exhaust fan(kw) |
電加熱功率
Electric heating power(kw) |
轉速
Rotate speed
(r/min) |
蒸氣壓力
Steam pressure
(MPa) |
備注
Note |
| SWA801-10 |
700×1100×1340 |
Φ640×560 |
0.55 |
0.55 |
7.2 |
46 |
0.4-0.6 |
電加熱型和蒸汽型號
Electric & steam type |
| SWA801-15 |
900×1200×1500 |
Φ760×560 |
0.75 |
0.75 |
10.8 |
35 |
0.4-0.6 |
| SWA801-30 |
1100×1450×1900 |
Φ950×860 |
1.1 |
1.1 |
18 |
32 |
0.4-0.6 |
| SWA801-50 |
1320×1700×2200 |
Φ1160×1000 |
1.5 |
1.5 |
21 |
32 |
0.4-0.6 |
| SWA801-100 |
1500×1800×2390 |
Φ1320×1100 |
2.2 |
2.2 |
39 |
30 |
0.4-0.6 |
| SWA801-100(雙) |
1620×1800×2410 |
Φ1500×1000 |
2.2 |
2×1.5 |
- |
30 |
0.4-0.6 |
雙引風
Double blower |
| SWA801-120 |
1620×1850×2410 |
Φ1500×1080 |
2.2 |
2×1.5 |
- |
28 |
0.4-0.6 |
| SWA801-150 |
1740×1900×2550 |
Φ1600×1160 |
3 |
2×2.2 |
- |
27 |
0.4-0.6 |
| SWA801-30T |
1100×1450×1900 |
Φ950×800 |
1.1 |
1.1 |
- |
32 |
- |
天然氣型,兩個燃燒頭
Gas type with two
combustion heads |
| SWA801-50T |
1320×1700×2200 |
Φ1160×1000 |
1.5 |
1.5 |
- |
32 |
- |
| SWA801-100T |
1485×1800×2360 |
Φ1320×1100 |
2.2 |
2.2 |
- |
30 |
- |
天然氣型,四個燃燒頭
Gas type with four
combustion heads |
| SWA801-120T |
1620×1850×2400 |
Φ1500×1080 |
2.2 |
2×1.5 |
- |
28 |
- |
| SWA801-150T |
1740×1900×2600 |
Φ1600×1160 |
3 |
2×2.2 |
- |
27 |
- |
| SWA801-50M |
1320×1700×2200 |
Φ1160×1000 |
1.5 |
2×0.75 |
- |
32 |
- |
燒木材型,外加引風機與燃燒爐
Wood-buring type with blower |
| SWA801-100M |
1485×1800×2360 |
Φ1320×1100 |
2.2 |
2×0.75 |
- |
30 |
- |
